The 2-Pin Micro Type-C Female Power Jack is a robust and modern charging solution designed for high-current power delivery in compact electronic devices. At Electrapac, we recommend this specialized connector for makers and repair technicians who want to upgrade older Micro-USB devices to the more durable and reversible USB-C standard.

Product Overview

Unlike standard 16-pin or 24-pin USB-C connectors used for high-speed data, this 2-Pin Version is simplified specifically for Power and Charging. By focusing only on the Positive (V_BUS) and Negative (GND) lines, it provides a much easier soldering experience for DIY projects, DIY power banks, and repairs of toys or rechargeable lamps.

Key Features for Electrapac Customers

• Reversible Convenience: Enjoy the "plug-in-either-way" benefit of USB-C. No more broken charging ports from trying to force a Micro-USB cable in the wrong direction.

• Heavy-Duty Power: Designed to handle up to 5A, making it suitable for fast-charging applications and high-power LED drivers that exceed the limits of older connectors.

• Easy Soldering Pads: Features two large, accessible solder lugs on the rear. This makes it ideal for beginners or for retrofitting existing devices that only require power input.

• Secure Mechanical Mounting: Equipped with side "wings" or mounting legs that can be soldered to the PCB for superior physical strength, preventing the port from being ripped off during frequent use.

• Heat Resistant Housing: Built with high-temperature plastic and a stainless steel shell to withstand the heat of soldering and long charging cycles.

Wiring & Retrofit Guide

The Electrapac 2-Pin Type-C socket is designed for simplicity. When looking at the rear solder pads:

1. VCC (+): The positive power input (usually 5V).

2. GND (-): The negative/common ground.

Pro-Tip: If you are using a "Smart" USB-C to USB-C cable (Power Delivery), some chargers may not provide power unless they detect a resistance on the "CC" pins. Since this is a 2-pin power-only jack, it is best used with USB-A to USB-C cables (Standard 5V chargers). If you must use a C-to-C cable, ensure your source is a standard 5V output.

Primary Applications

• Micro-USB to Type-C Upgrades: Replacing broken Micro-USB ports in Bluetooth speakers, headphones, or rechargeable fans.

• DIY Power Banks: Creating custom portable chargers for your Arduino or ESP32 projects.

• Electronic Toys: Upgrading battery-operated toys to be rechargeable via modern phone chargers.

• LED Strip Power: Providing a clean, modern power input for 5V addressable LED (WS2812B) setups.

• 3D Printed Enclosures: Designing custom gadgets that require a professional-looking external power port.

Why Shop at Electrapac?

We source our Type-C Female Jacks with reinforced steel shells to ensure they stand up to the daily wear and tear of the Bangladeshi environment. Visit us at www.electrapac.com for the modern connectors that keep your devices powered into the future.
