The MP1584 DC-DC Step-Down Buck Converter is an ultra-compact, high-frequency voltage regulator designed for projects where space is at a premium. At Electrapac, we recommend this module as the "smaller, smarter" alternative to the LM2596, especially for drones, RC planes, and miniature IoT devices.

Product Overview

The MP1584 is a high-frequency switching regulator with a built-in internal power MOSFET. Because it operates at a high switching frequency of 1.5MHz, it can use much smaller inductors and capacitors than older modules, resulting in a tiny footprint (roughly the size of a postage stamp). Despite its size, it can handle up to 3A of output current with high efficiency.

Key Features for Electrapac Customers

• Ultra-Compact Size: It is one of the smallest 3A buck converters available, making it the top choice for Electrapac customers building wearable tech or compact drones.

• High-Frequency Performance: The 1.5MHz switching speed ensures a very clean output with minimal electrical noise, which is critical for sensitive RF and audio equipment.

• Efficiency: With up to 96% efficiency, very little energy is wasted as heat, which extends the battery life of your portable projects.

• Fine-Tuning: Features a tiny on-board potentiometer to precisely set voltages for ESP32 (3.3V), Arduino (5V), or FPV cameras (12V).

• Wide Input Range: Capable of handling up to 28V, allowing you to power 5V logic directly from a 6S LiPo battery pack.

Setup & Usage Guide

To get the best performance out of this Electrapac power module:

1. Solder Connections: The module uses solder pads rather than screw terminals to keep the profile slim. Ensure you use high-quality solder for a low-resistance connection.

2. Voltage Adjustment: Use a small flat-head screwdriver to turn the potentiometer. Note: On many MP1584 boards, the potentiometer is very sensitive. Always monitor the output with a multimeter before connecting your load.

3. Heat Management: While rated for 3A, the tiny surface area means heat builds up quickly. For continuous loads above 1.5A, ensure the module has good airflow or is mounted to a small heat sink.

4. Fixed Voltage Hack: Advanced users often remove the potentiometer and bridge specific pads to create a "Fixed" 3.3V or 5V output for even greater stability.

Primary Applications

• FPV Drones & RC Gear: Stepping down high-voltage LiPo batteries to power flight controllers and video transmitters.

• Portable Electronics: Creating 5V USB power from 12V or 24V battery systems in tight enclosures.

• IoT & Sensors: Powering ESP8266/ESP32 modules that require a steady 3.3V from a 12V adapter.

• DIY Smart Home: Integrating into small junction boxes where larger converters (like the LM2596) won't fit.

• Mobile Robotics: Providing regulated power to logic boards while the main battery drives the motors.

Why Shop at Electrapac?

We source the MP1584 Modules with high-grade ceramic capacitors to ensure long-term reliability and stable voltage delivery. At www.electrapac.com, we provide the high-density power solutions that help you shrink your projects without sacrificing performance.
