A Mini Slide Switch (SPDT) is a compact, board-friendly mechanical switch used to toggle between two circuits or to act as a simple ON/OFF power control for small devices.

Because it is an SPDT (Single Pole Double Throw) switch, it features three pins: a center "Common" pin and two outer pins. Sliding the lever connects the center pin to one of the two sides.

Features & Functionality

• Simple Logic: The center pin is always "Common."

  • Slide Left: Connects Center Pin to Left Pin.

  • Slide Right: Connects Center Pin to Right Pin.

• Maintained Action: This is a "stay-put" switch; it remains in the position you slide it to until you move it back.

• Compact Design: Ideal for handheld electronics where space is at a premium, such as toys, calculators, or wearable tech.

• Breadboard Friendly: Most standard mini slide switches have a 0.1-inch pin spacing, making them perfect for prototyping with Arduinos or breadboards.

Common Applications

• Power Toggles: Turning a battery-powered DIY project ON or OFF.

• Mode Selection: Toggling between two modes (e.g., "High Volume" vs. "Low Volume" or "Mode A" vs. "Mode B").

• Input Selector: Choosing between two different signal sources for a microcontroller.

• DIY Gadgets: Used extensively in hobbyist robotics, LED flashlights, and small audio devices.

⚠️ Handling Note

Heat Sensitivity: When soldering these to a PCB, avoid applying heat to the pins for more than 2–3 seconds. Because the body is plastic, the internal metal contacts can shift if the plastic gets too soft from excess heat, ruining the switch mechanism.
