The 1203BK 3A DC Motor Speed Controller (PWM) is an efficient and reliable solution for controlling the speed of small to medium DC motors. At Electrapac, we recommend this compact regulator for hobbyists and DIY enthusiasts in Bangladesh who are building RC cars, custom cooling fans, or small automated machinery requiring precise speed adjustment.

Product Overview

The 1203BK utilizes Pulse Width Modulation (PWM) to control motor speed. Unlike simple voltage dividers that waste energy as heat, PWM maintains high torque even at low speeds by rapidly switching the power on and off. With a wide input range of 6V to 28V and a maximum current of 3A, this module is versatile enough to handle most common DC hobby motors and LED strips.

Key Features for Electrapac Customers

• Smooth Speed Control: The integrated potentiometer allows for seamless adjustment from zero to full speed with a satisfying mechanical "click" for the OFF position.

• Energy Efficient: Because it uses PWM technology, the module stays cool and preserves battery life, making it ideal for portable, battery-powered projects.

• High-Current Protection: Equipped with a 3A fuse to protect the internal circuitry and your motor from accidental overcurrent or short circuits.

• Easy Installation: Features four sturdy screw terminals (Power In +, Power In -, Motor +, Motor -), eliminating the need for soldering during the initial setup.

• Compact & Durable: The small PCB footprint and high-quality electrolytic capacitors ensure it can be tucked away inside small enclosures or robot chassis.

Wiring & Operation Guide

Setting up the Electrapac 1203BK is simple, but correct polarity is essential for safety:

1. Power Input: Connect your DC power source (6V–28V) to the Power + and Power - terminals. Warning: Reverse polarity on the input side may damage the controller.

2. Motor Output: Connect your DC motor to the Motor + and Motor - terminals.

3. Direction Control: If the motor spins in the wrong direction, simply swap the two motor wires.

4. Adjustment: Turn the knob clockwise to turn the unit "ON" and increase speed. Turn it fully counter-clockwise until it clicks to turn it "OFF."

Pro-Tip: While this controller is rated for 3A, if you are running it at its maximum limit for long periods, ensure the module is placed in a well-ventilated area to dissipate heat from the MOSFET.

Primary Applications

• DC Motor Speed Control: Adjusting the speed of 12V or 24V motors in robotics and DIY tools.

• LED Dimming: Controlling the brightness of 12V-24V LED strips (non-addressable) for home decor or display cases.

• Fan Speed Adjustment: Reducing the noise of high-speed cooling fans in computer cases or inverter cabinets.

• Pump Control: Regulating the flow rate of small 12V water pumps for hydroponics or fountains.

• Model Trains & RC: Providing precise throttle control for model railway layouts.

Why Shop at Electrapac?

We source our 1203BK Controllers with high-tolerance components to ensure stable PWM frequencies and long-term durability under varying loads. Visit us at www.electrapac.com for the power management modules that give you total control over your hardware.
