The 12V 4-Channel Relay Module with Opto-Isolation is a robust industrial-grade switching solution designed for high-voltage control. At Electrapac, we recommend this 4-channel version for complex automation projects where you need to manage multiple independent AC or DC loads simultaneously from a single 12V power source.

Product Overview

This module allows your microcontroller (Arduino, Raspberry Pi, or PLC) to safely toggle up to four high-power devices. Unlike the 5V versions, this module is optimized for 12V systems, making it the perfect choice for automotive applications, 12V solar systems, and industrial control cabinets. Each channel is equipped with an Optocoupler, which provides an electrical "firewall" between your high-voltage appliances and your delicate low-voltage logic controller.

Key Features for Electrapac Customers

• Full Opto-Isolation: Each of the four channels has its own optical isolator. This ensures that even if a relay coil fails or a power surge occurs on the load side, your microcontroller remains completely protected.

• 4-Channel Independent Control: Manage four separate devices—such as a pump, a light, a heater, and a fan—independently using only 4 signal pins from your controller.

• LED Status Indicators: Each relay has a dedicated LED that glows when the channel is active, allowing for rapid visual troubleshooting and system monitoring.

• High-Current Handling: Every relay is rated for 10A, providing enough "muscle" for most household appliances and industrial actuators.

• Standard Interface: The input pins are standard 2.54mm pitch, making them perfectly compatible with the jumper wires and breadboards found at www.electrapac.com.

Wiring & Connection Guide

For a reliable setup using Electrapac components:

1. VCC/GND: Connect to a stable 12V DC power supply to power the relay coils.

2. Input Pins (IN1 - IN4): Connect to your Arduino/Microcontroller digital output pins.

3. The Output Terminals: Each relay features:

   • COM (Common): The main power feed.

   • NO (Normally Open): The device stays OFF until the relay is triggered.

   • NC (Normally Closed): The device stays ON until the relay is triggered.

Primary Applications

• Automotive Automation: Controlling 12V car accessories, horns, or custom lighting kits.

• Smart Home Systems: Managing multi-zone lighting or automated appliance switching.

• Industrial Control: Operating 12V solenoids, valves, and heavy-duty contactors in factory environments.

• Solar Power Management: Switching between battery banks or controlling DC loads in off-grid setups.

Why Shop at Electrapac?

We source our 12V 4-Channel Modules with high-quality Songle relays and reinforced PCB traces to ensure longevity under continuous load. At www.electrapac.com, we provide the reliable switching power you need to scale up your automation ideas.
