The NEO-7M GPS Module is a high-performance satellite positioning receiver designed to provide exceptional sensitivity and precision for your electronics projects. At Electrapac, we recommend this module for developers who need a reliable upgrade from the older NEO-6M, as it offers better signal acquisition and lower power consumption.

Product Overview

The NEO-7M is built around the advanced u-blox 7 positioning engine. It is a multi-GNSS module, meaning it can track various satellite constellations including GPS, GLONASS, Galileo, and QZSS, ensuring a stable "fix" even in challenging urban environments.

Key Features

• Dual Antenna Support: Comes with an on-board high-gain ceramic patch antenna for standalone use and an SMA connector for attaching an external high-gain antenna for better reception inside vehicles.

• Built-in EEPROM: Allows you to save configuration changes (like baud rate or update frequency) so they persist even after power-off.

• Signal Indicator: Features an on-board LED that flashes when a satellite fix is successful, providing instant visual feedback.

• Backup Battery: Includes a small rechargeable battery to store "ephemeris data," which enables Hot Starts (re-acquiring your location in seconds after a brief power loss).

• NMEA Protocol: Outputs standard NMEA sentences, making it compatible with almost all GPS software and libraries (like TinyGPS++).

Connectivity Guide

The module uses a simple 4-pin or 5-pin header for easy wiring:

1. VCC: Connect to 3.3V or 5V.

2. GND: Connect to Ground.

3. TXD: Connect to the RX pin of your microcontroller.

4. RXD: Connect to the TX pin of your microcontroller.

5. PPS (Optional): Pulse-Per-Second output for high-precision timing applications.

Pro-Tip for Electrapac Customers: For the first use, we recommend testing the module outdoors or near a window. It can take up to 10 minutes to download the full satellite almanac for its very first "Cold Start" fix.

Visit Electrapac for More

For technical datasheets, sample Arduino sketches, and more high-quality components, visit us at www.electrapac.com
