The antenna features a built-in Low Noise Amplifier (LNA) that amplifies weak satellite signals before they reach your receiver, ensuring a faster "Time to First Fix" (TTFF) and better positioning accuracy.

Key Features

• Magnetic Mounting: The base contains a powerful magnet, allowing for instant attachment to a car roof, trunk, or any flat metallic surface without drilling or permanent adhesive.

• Plug-and-Play Compatibility: The standard SMA connector is compatible with most aftermarket car head units (Pioneer, Kenwood, Alpine), GPS trackers, and microcontrollers like the A9G module or Arduino GPS shields.

• High Sensitivity: With a noise figure typically below 1.5dB, it can pull in signals even in "noisy" RF environments.

• Right-Hand Circular Polarization (RHCP): Optimized specifically for the way GPS satellite signals are transmitted, ensuring maximum signal capture.

Installation & Usage Tips

1. Placement: For the best results, place the antenna on the highest point of the vehicle (the roof) with a clear view of the sky. The metal roof actually acts as a "ground plane," which further improves antenna performance.

2. Cable Routing: The 3-meter cable is thin and flexible (RG174), making it easy to tuck into weather stripping or interior panels to hide the wire.

3. Check Your Connector: Ensure your device has an SMA Female port (threaded on the outside with a center hole). If your device uses a push-on connector (like SMB or MCX), you will need an adapter.

Ideal For:

• Replacing lost or damaged factory GPS antennas in cars and boats.

• Enhancing the accuracy of fleet management and theft-recovery trackers.

• Improving GPS signal for flight controllers in drones or robotic rovers.
