The Autonics TCN4S-24R is a dual-display, high-performance PID temperature controller designed for industrial thermal management. At Electrapac, we recommend this specific model for its "Dual-PID" control algorithm, which provides rapid response and minimal overshoot, ensuring your heating processes remain stable and precise.

Product Overview

The TCN4S-24R belongs to the TCN Series, which is highly regarded for its cost-effectiveness and reliability. It features a 1/16 DIN compact size and a dual digital display that allows you to see both the Present Value (PV) in red and the Set Value (SV) in green simultaneously. This makes it an excellent choice for ovens, plastic extrusion machines, and industrial furnaces.

Key Features for Electrapac Customers

• Dual PID Control: Features two PID modes: "High-speed response" to reach the set temperature quickly, and "High-precision" to minimize temperature fluctuations once the target is reached.

• Universal Input: At Electrapac, we value versatility. This controller supports multiple thermocouple types and RTDs, allowing you to use it with your existing industrial sensors.

• Dual Output Modes: You can choose between standard Relay output for mechanical switching or SSR (Solid State Relay) drive for high-speed, silent switching applications.

• Auto-Tuning Function: Simplifies the setup process by automatically calculating the ideal PID constants for your specific heating system.

• Large Digital Display: The high-luminance LEDs ensure the temperature is readable even in dusty or dimly lit factory environments.

Wiring & Connection Guide

To ensure safe operation of your Electrapac industrial equipment, follow this standard terminal layout:

1. Power (Terminals 1 & 2): Connect your 100V–240V AC mains supply.

2. Sensor Input (Terminals 10, 11, 12): * For Thermocouples: Use pins 11 (+) and 12 (-).

   • For 3-wire RTD (Pt100): Use pins 10, 11, and 12.

3. Control Output (Terminals 3, 4, 5): Use pins 4 and 5 for the Relay contact. If using an SSR, use the dedicated SSR drive terminals (refer to your specific unit label).

4. Alarms (Terminals 7, 8, 9): Configure these for over-temperature protection or system fault alerts.

Primary Applications

• Plastic Processing: Precise temperature control for injection molding and extrusion.

• Food Industry: Managing heat in industrial ovens, deep fryers, and packaging machines.

• Laboratories: Maintaining stable environments in incubators and kilns.

• HVAC Systems: Controlling large-scale boiler and furnace temperatures.

• Manufacturing: Used in heat treatment furnaces and soldering stations.

Why Shop at Electrapac?

We source genuine Autonics TCN4S-24R units to ensure you receive a controller that meets international safety standards (CE and UL). Visit us at www.electrapac.com for the precision control hardware that keeps your production line running smoothly.
